- 流路幾何形狀將乾淨的沖洗與最小的內部容積相結合
- 可定製尺寸，可供OEM使用
- 大容量阻尼器可提高阻尼效率和範圍
- 可製造為包括壓力感測器和/或主清洗閥
- 提供UHPLC阻尼器
ASI FlatLine脈衝阻尼器將性能和可靠性結合在一個簡單易用的外殼中。Standard 10-32 入口和出口埠允許快速連接到幾乎任何 HPLC 系統。堅固的核心技術提供可靠的長期運行，而不會因阻尼器膜破裂或洩漏而導致停機時間。定製尺寸和附加功能，如一體式灌注/清洗閥，可用於OEM市場。對於超臨界CO2應用，590-0002型 將提供可靠的長期性能。
Standard HPLC Pulse Damper
產品規格：
Standard 10-32 inlet and outlet portsPressure Rating: 6,000 PSI max operating pressure
Proof Pressure: 9,000 PSI
Dead Volume: 350 µL @ zero PSI, 650 µL @ 1,500 PSI
Temperature: 40°C max operating temperature
Dimensions: 3.8" long x 1.5" diameter
CO² compatible Standard HPLC Pulse Damper
產品規格：Standard 10-32 inlet and outlet ports
Pressure Rating: 6,000 PSI max operating pressure
Proof Pressure: 9,000 PSI
Dead Volume: 450 µL @ zero PSI, 750 µL @ 1,500 PSI
Temperature: 40°C max operating temperature
Dimensions: 3.8" long x 1.5" diameter
High Capacity Standard HPLC Pulse Damper
產品規格：Standard 10-32 inlet and outlet ports
Pressure Rating: 4,000 PSI max operating pressure
Proof Pressure: 6,000 PSI
Dead Volume: 2 mL @ 1,500 PSI
Temperature: 40°C max operating temperature
High Volume Ultra High Pressure HPLC Pulse Damper (UHPLC)
產品規格：
Standard 10-32 inlet and outlet ports
Pressure Rating: 18,000 PSI max operating pressure
Proof Pressure: 27,000 PSI
Dead Volume: 300 µL @ zero PSI, 1.15 mL @ 1,500 PSI
Temperature: 40°C max operating temperature
Low Volume Ultra High Pressure HPLC Pulse Damper (UHPLC)
產品規格：Standard 10-32 inlet and outlet ports
Pressure Rating: 18,000 PSI max operating pressure
Proof Pressure: 27,000 PSI
Dead Volume: 265 µL @ zero PSI, 775 µL @ 18,000 PSI
Temperature: 40°C max operating temperature
